| Frequency Response |
20 Hz - 20 kHz, +0/-1 dB (at 1 watt) |
| THD |
<0.5%, 20 Hz - 20 kHz |
| Intermodulation Distortion |
=/ <0.35% (60 Hz and 7 kHz at 4:1 from full rated ouput to -30 dB) |
| Slew Rate |
>10V/us |
| Voltage Gain |
29 dB |
| Damping Factor |
(8 ohms, 10 Hz to 400 Hz) >200 |
| Signal To Noise Ratio (A-weighted) |
>100 dB |
| Crosstalk (below rated power) 20 Hz to 1 kHz |
-75 dB, -59 dB |
| Input Sensitivity |
(for full rated power at 8 ohms) 0.775V or 1.4V |
| Input Impedance (nominal balanced, unbalanced) |
20kΩ, 10kΩ |
| AC Line Voltage and Frequency Configurations Available |
(+10%) 120V~60 Hz; 220V~50/60 Hz; 230-240V~50/60 Hz |
| Dimensions |
19" x 3.5" x 12.4" (48.3cm x 8.9cm x 31.5cm) |
| Weight |
25.1lbs (11.4kg) |
| IEC Power Connector |
15A |
