| Input Connectors |
6 inputs (2 Mono Mic/Line, 2 x Stereo) |
| Channels |
Channels 1-2: XLR-1/4" / 6.35 mm jack combo connectors (XLR is a mic level input, 1/4" is a line level input)
Channels 3-4: 2x 1/4"/ 6.35 mm balanced TRS jacks (stereo) and 2x RCA jacks (stereo)
Channels 5-6: Stereo 1/8" / 3.5 mm jack |
| Input Impedance |
Channels 1-2 Combo XLR: 40 kOhms balanced
Channels 1-2 Combo TRS: 40 kOhms balanced
Channels 3-4 TRS: 20 kOhms balanced
Channels 3-4 RCA: 5 kOhms unbalanced
Channels 5-6 3.5 mm: 10 kOhms unbalanced |
| Bluetooth |
Channels 5-6: Bluetooth audio streaming |
| Output Connectors |
Monitor Outputs: 2x RCA jacks (stereo) |
| Signal Indicator |
Limit: Yellow LED indicates limiter active condition |
| EQ Section |
Channels 1 & 2: Individual bass and treble controls, center detent, ±12 dB cut and boost |
| Limiter |
On-board DSP limiting and tuning |
