| Type | Active, band-pass |
| Frequency Range | 45 to 160 Hz (-10 dB) |
| SPL | 132 dB maximum |
| Amplifier | Class-D, 950 W dynamic, 600 W continuous |
| Woofer | 15" (381 mm) cone woofer with 2.5" voice coil and ferrite magnet |
| Controls | Level, Polarity, LPF, D-XSUB, Front LED disable, Power |
| Connectors | 2 x XLR inputs 2 x XLR thru connectors (parallel with inputs) 1 x AC power input |
| Input Impedance | 10 kOhms |
| Input Sensitivity | +1 dBu max, +11 dBu center |
| Input Level | +24 dBu max |
| Low-Pass Filter | 80/100/120 Hz, 24 dB/oct |
| DSP | D-XSUB: Normal, Boost, Xtended LF, Off |
| Cabinet | Wood with black painted finish and 2 metal side handles |
| Mounting | 1 x Top panel 35 mm pole socket |
| Power Requirements | 100 to 240 VAC, 50/60 Hz |
| Power Consumption | 120 W (1/8 rating) |
| Dimensions (WxHxD) | 18.9 x 24.4 x 24.5" (478 x 618 x 624 mm) |
| Weight | 83.8 lb (38 kg) |
| Packaging Info | |
|---|---|
| Package Weight | 93.25 lb |
| Box Dimensions (LxWxH) | 30.0 x 28.0 x 22.0" |
